Through Colored Fiber Cement Board

Suitable for exterior wall curtains, interior partitions, and ceilings
Laying methods: Rivets, grooved slide rails

Product Gallery

Product Overview – Through-Colored Cement Board

The Through-Colored Fiber Cement Board is a thin panel made from Portland cement, plant fibers, quartz, and other natural minerals through high-temperature and high-pressure steaming. It is a panel with uniform color, varied styles, excellent strength, and weather resistance.

Specifications & Dimensions

Thickness

Width

Length

6,8,9,12,15mm

1220mm

2440,3050mm

REMARK: We can also supply other specification as the client’s specially requirement

Item

Index

Unit

Density

≥1.40

g/cm3

Thermal Conductivity

≤0.35

W/(m·k)

Water Absorption

≤28

%

Water Contain

≤10

%

Moisture Movement

≤0.25

%

Freezing

No cracking or delaminating after 50 times of freeze-thaw cycles

Non-water soaking

No Water Forms after being tested for 24 hours

Non-combustibility

A1

/

Bending
Strength

Oven dry

Cross

≥20.0

Mpa



Parallel

≥15.0

Mpa



Saturated

Cross

≥15.0

Mpa



Parallel

≥10.0

Mpa

Screwing withdraw

≥110

N/mm

Impact resistance

Oven dry

No Continuous Cracking After An Impact

/

Non-combustibility

A

the highest grade

REMARK: Please contact our technical department if you need more technical index.

Applications of Through-Colored Fiber Cement Boards

Particularly suitable for exterior walls and curtain walls of modern high-end buildings, renovation projects, typhoon-prone and cold regions, as well as interior partitions and ceilings in high-traffic areas such as public venues.

tandard Sizes & Custom Options

Key Features of Through-Colored Cement Board

Suitable for Large Surface Coverage

The length and width of a single board reach 2440mm and 1220mm, approximately 3 square meters. During installation, fewer boards can cover a larger area, enabling faster installation and laying.

Lightweight

When selecting building materials of the same thickness, the light weight of the board reduces the load on the building. Additionally, the construction method of fixing with metal hangers prevents cracking and peeling of the exterior wall, ensuring user safety.

Weather Resistance

Tested in a low-temperature freezer at -20°C to 2°C for 90 minutes, then taken out and melted in clear water at 20°C to 5°C for 30 minutes (one cycle). After 25 freeze-thaw cycles, no cracking or delamination occurs.

High Strength & Impact Resistance

Minimum flexural strength (parallel to fiber direction) ≥ 15 MPa; maximum flexural strength (perpendicular to fiber direction) ≥ 20 MPa. Tested in accordance with GB/T 15227-2007 *Testing Methods for Air Tightness, Water Tightness, and Wind Pressure Resistance of Building Curtain Walls*.

Thermal Insulation

With a low thermal conductivity (approximately 0.35 W/m·K), its excellent thermal insulation performance effectively improves the heat preservation effect of walls, reducing heat loss and achieving a “warm in winter and cool in summer” effect.

Self-Cleaning Surface

The board’s own waterproof performance effectively prevents outdoor liquids from penetrating. The unique lotus leaf effect makes raindrops falling on the board quickly condense into water droplets, which carry surface dust away rapidly.

Installation Systems

Back Bolt with Rear Groove System

Rivet Fixing System

Why Choose Us

Comparison with Similar Products from Peers

Cost-Effectiveness

With full certification for export to European markets, JOINBLING fiber cement boards deliver excellent cost-performance compared to similar brands. They meet international safety and durability standards while providing a reliable, affordable solution tailored to modern construction needs.

Superior Quality

Many counterfeit boards fail to meet basic flexural strength standards. In contrast, JOINBLING boards pass strict curtain wall performance tests, including air tightness, water resistance, wind pressure, and planar deformation. This ensures consistent strength, high density, and minimal warping or structural instability.

High Manufacturing Standards

Compared to low-grade products from asbestos-based or unregulated factories, JOINBLING boards offer superior quality—featuring uniform thickness, minimal surface defects, consistent texture, and stable color performance. These qualities ensure aesthetic consistency and long-term reliability in professional applications.

Generation process

Raw material preparation

We carefully select and proportion high-quality raw materials such as plant fibers, cement, silica, and additives. This step ensures the strength of the base layer of the fiber cement board, laying a solid foundation for its durability, dimensional stability, and resistance to harsh environmental conditions.

Stirring processing

All raw materials are mixed into a uniform slurry using an advanced automated system. The precise mixing process ensures uniform fiber distribution and stable composition, which is essential to ensure the consistent performance of each fiber cement board.

Pressure forming

The fully mixed slurry is pressed under high pressure to compact the material into a dense and hard board. The pressing process strengthens the structure of the fiber cement board and improves its ability to resist cracking, warping, and long-term wear and tear due to moisture or wind and sun.

Board Maintenance

After pressing, the raw board is moved into a controlled curing environment with strict temperature and humidity settings. This board curing process promotes cement hydration so that each board achieves the best mechanical properties and surface hardness.

烘干卸板机

Drying

Partially cured boards enter the drying room to remove excess moisture. Once dry, it is carefully unloaded and prepared for subsequent processing. This critical step prevents the finished fiber cement board from deforming, mold or internal stress.

Cutting

The dried boards are cut using automated precision cutting machines to form standard or custom sizes. Precise dimensions and smooth edges ensure installation efficiency and meet architectural design standards for fiber cement board applications.

Quality Inspection

Each fiber cement board undergoes a strict quality control process, including size, thickness, strength, and appearance inspections. Only boards that meet international standards such as CE or AS/NZS are approved for distribution.

Product storage

Finished boards are stacked and stored in moisture-proof, organized storage areas. Proper labeling, protective packaging, and inventory control ensure that fiber cement boards maintain quality during transportation and can be delivered quickly around the world.

Our Happy Clients!

FAQs—About Colored Fiber Cement Board

1. What are the advantages of fiber cement boards?

JOINBLING produces fiber cement boards using raw materials such as cement and plant fibers, which offer longer service life and better quality assurance than traditional wooden boards. They have strong waterproof, fireproof, and insect-proof functions, ensuring safety and greatly reducing maintenance needs. JOINBLING’s technology helps maintain color and prevent fading. The high quality and diverse functions of fiber cement boards make them a cost-effective and stylish choice for any home.

JOINBLING adheres to environmentally sustainable manufacturing practices, producing products with longer lifespans, better quality, and contributions to green environmental protection. The Through-Colored Board is made from raw materials such as Portland cement, plant fibers, and quartz—100% asbestos-free and formaldehyde-free.

 JOINBLING finishes offer a curated selection of colors covering the most popular exterior shades. Most people should be able to find the perfect tone for their home in our range.

 Budget is a factor, but more considerations include the total cost over the lifecycle and product durability. Therefore, choosing a product that resists rain, sun, fire, and pests and continues to protect your home for decades will greatly reduce repair and maintenance costs. The Through-Colored Board, made of fiber cement, is designed to withstand daily damage from nature and will not burn or fuel fires when directly exposed to fire. Of course, JOINBLING offers unique wall panel styles and colors to help enhance your home’s appearance, allowing you to find the perfect choice.

Cement boards (such as JOINBLING Through-Colored Boards) are waterproof panels that provide a durable base for tile installation. When completing water-related projects, cement boards are essential for protecting interior gypsum boards from moisture. Place them between your tiles and the subfloor for excellent tile adhesion and waterproofing. Cement boards offer higher compressive strength compared to competitors’ panels.

The cost of board projects is influenced by many factors, such as the size of your home, the application scenario, the selected product materials, and supporting facilities. This will help you best estimate the cost. You can also call us for consultation.
